| Place of Origin: | China |
| اسم العلامة التجارية: | IONPURE |
| إصدار الشهادات: | CE |
| Model Number: | IP-LXM18Z-5 |
| الوثيقة: | fgwater-ionpure-lxz-ds.pdf |
| Minimum Order Quantity: | 1 pc |
|---|---|
| الأسعار: | قابل للتفاوض |
| Packaging Details: | standard export packing |
| Delivery Time: | 5- 8 work days |
| شروط الدفع: | T/T ، Western Union |
| Supply Ability: | 60000 Units per Month |
| 18Z-5 Minimum Flow Rate m3/hr (gpm): | 1.02 (4.5) | 18Z-5 Design Flow Rate m3/hr (gpm): | 2.0-3.1 (9.0-13.5) |
|---|---|---|---|
| 18Z-5 Shipping Weight kg (lbs)**: | 99 (217) | 18Z-5 Operating Weight kg (lbs): | 74 (163) |
| 18Z-5 الانتعاش: | 90-95% | Stack Advantages: | Wide Range Of Flow,Low Operating Costs,Super Strong Electrical Insulation |
| Stack DC Voltage: | 0–400 | Stack DC Amperage: | 1.0–6.0 |
| Application: | Industrial Applications | ||
| إبراز: | Industrial EDI module for ultrapure water,Ionpure CEDI LX-Z EDI module,EDI module with IP-LXM18Z-5 model,Ionpure CEDI LX-Z EDI module,EDI module with IP-LXM18Z-5 model |
||
| Attribute | Value |
|---|---|
| Minimum Flow Rate (m3/hr/gpm) | 1.02 (4.5) |
| Design Flow Rate (m3/hr/gpm) | 2.0-3.1 (9.0-13.5) |
| Shipping Weight (kg/lbs) | 99 (217) |
| Operating Weight (kg/lbs) | 74 (163) |
| Recovery Rate | 90–95% |
| Stack DC Voltage | 0–400 |
| Stack DC Amperage | 1.0–6.0 |
| Primary Application | Industrial Processes |
| Parameter | Value |
|---|---|
| Product Water Resistivity | Minimum Flow > 17 MW-cm* Maximum Flow > 7 MW-cm* |
| Silica (SiO2) Removal | 90-99% (feed dependent) |
| Parameter | Specification |
|---|---|
| Conductivity | < 40 μS/cm |
| Source | RO permeate |
| Temperature | 5-45˚C (41-113˚F) |
| Total Chlorine | < 0.05 ppm |
| Iron/Manganese | < 0.01 ppm |
| Total Hardness | < 1.0 ppm |
| Model | Length (mm/in) | Width (mm/in) |
|---|---|---|
| LXM18Z | 488.2 mm (19.22") | 353.8 mm (13.93") |
